| MODEL | IP | VOLTAGE (V) | Power Consumption |
Classification | DIMENSIONS | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| D (ΓΈ) | H | ||||||||||
| IL-EXP-A2 | IP65 | AC176/264V | 20W/40W/60W | Zone1 | Zone2 | Zone21 | IIA | IIB | IIC | 280 | 240 |
Explosion Rating EXDII
Working Temperature -40c ~ 60c / -40f ~ 140f
Typical Application:
Tunnel | Factory | Petrol Station | Inflammable Area | Detonable Area
Note: Initial charge for emergency function should be more than 24hours.
Features & Characteristic:
Explosion proof design
Built-in auto-recharge emergency function
80% lumen maintenance over 50,000hours
Built-in surge protection
Maintenance free
Mercury free
No UV or IR
Universal input without additional adapter ,
40-315Vac, 40-400Vdc
Instant start and flicker free
High uniformity and color rendering
